Configure HAProxy for HA Setup

1. Install HAProxy by executing the command:

   sudo apt install haproxy
2. Edit the HAProxy config file by updating the Operator console's IP address.

   /etc/haproxy/haproxy.cfg

   Before applying this configuration, substitute all placeholder values with your actual IP addresses and domain name. The IP addresses shown below are for documentation purpose only and are not routable.

   #---------------------------------------------------------------------
   # Proxys to the webserver backend port 443
   #---------------------------------------------------------------------

   # OPTIONAL: Stats endpoint — remove this block if not needed.
   # If enabled, restrict access to a trusted interface or add authentication.
   frontend stats
       mode http
       bind 127.0.0.1:80
       stats enable
       stats uri /stats
       stats refresh 10s
       stats admin if LOCALHOST
       # Uncomment the following line to require a username and password:
       # stats auth admin:<strong-password>

   frontend https
           bind :443
           mode tcp
           option tcplog
           # Wait for a client hello for at most 5 seconds
           tcp-request inspect-delay 5s
           tcp-request content accept if { req_ssl_hello_type 1 }
           use_backend controller_ssl if { req_ssl_sni -m end .customer-domain }
           #default_backend static

   frontend ops_https
           bind :9443
           mode tcp
           option tcplog
           # Wait for a client hello for at most 5 seconds
           tcp-request inspect-delay 5s
           tcp-request content accept if { req_ssl_hello_type 1 }
           use_backend opsui_ssl if { req_ssl_sni -i ops-ui.prisma-sd-wan.com }

   backend controller_ssl
           mode tcp
           balance roundrobin
           timeout connect 5s     # 5 seconds
           timeout check 5s       # 5 seconds
           timeout server 30s     # 30 seconds
           server controller_ssl_server1 app-node-1-IP:443 check
           server controller_ssl_server2 app-node-2-IP:443 check backup
           server controller_ssl_server3 app-node-3-IP:443 check backup

   backend opsui_ssl
           mode tcp
           balance roundrobin
           timeout connect 5s     # 5 seconds
           timeout check 5s       # 5 seconds
           timeout server 30s     # 30 seconds
           server ops_ssl_server1 ops-node-1-IP:9443 check
           server ops_ssl_server2 ops-node-2-IP:9443 check backup
           server ops_ssl_server3 ops-node-3-IP:9443 check backup

   Replace the following placeholders before applying this configuration:

   • customer-domain — your tenant domain.
   • app-node-1-IP, app-node-2-IP, app-node-3-IP — the IP addresses of your 3 Application nodes.
   • ops-node-1-IP, ops-node-2-IP, ops-node-3-IP — the IP addresses of your 3 Operator nodes.
