You can base the report on one of the following database types:

The columns that you want to use as the match criteria. The attributes are the columns that are available for selection in a report. From the list of

Available Columns

, you can add the selection criteria for matching data and for aggregating the details (the

Selected Columns

).

The

Sort By

and the

Group By

criteria allow you to organize/segment the data in the report; the sorting and grouping attributes available vary based on the selected data source.

The Sort By option specifies the attribute that is used for aggregation. If you do not select an attribute to sort by, the report will return the first N number of results without any aggregation.

The Group By option allows you to select an attribute and use it as an anchor for grouping data; all the data in the report is then presented in a set of top 5, 10, 25 or 50 groups. For example, when you select Hour as the Group By selection and want the top 25 groups for a 24-hr time period, the results of the report will be generated on an hourly basis over a 24-hr period. The first column in the report will be the hour and the next set of columns will be the rest of your selected report columns.

The following example illustrates how the

Selected Columns

and

Sort By

/

Group By

criteria work together when generating reports:

The columns circled in red (above) depict the columns selected, which are the attributes that you match against for generating the report. Each log entry from the data source is parsed and these columns are matched on. If multiple sessions have the same values for the selected columns, the sessions are aggregated and the repeat count (or sessions) is incremented.

The column circled in blue indicates the chosen sort order. When the sort order (

Sort By

) is specified, the data is sorted (and aggregated) by the selected attribute.

The column circled in green indicates the

Group By

selection, which serves as an anchor for the report. The

Group By

column is used as a match criteria to filter for the top N groups. Then, for each of the top N groups, the report enumerates the values for all the other selected columns.

For example, if a report has the following selections:

The output will display as follows:

The report is anchored by

Day

and sorted by

Sessions

. It lists the 5 days (

5 Groups

) with maximum traffic in the

Last 7 Days

time frame. The data is enumerated by the

Top 5

sessions for each day for the selected columns—

App Category

,

App Subcategory

and

Risk

.

The date range for which you want to analyze data. You can define a custom range or select a time period ranging from the last 15 minutes to the last 30 days. The reports can be run on demand or scheduled to run at a daily or weekly cadence.
