Integrate Cloud Identity Engine with Prisma Access
Focus
Focus
Prisma Access

Integrate Cloud Identity Engine with Prisma Access

Table of Contents

Integrate Cloud Identity Engine with
Prisma Access

Integrate the Cloud Identity Engine to implement Directory Sync with Prisma Access.
Where Can I Use This?
What Do I Need?
  • Prisma Access (Cloud Management)
  • Prisma Access (Panorama Managed)
  • Prisma Access
    license

Cloud Management

Cloud Identity Engine (Directory Sync) gives
Prisma Access
read-only access to your Active Directory information, so that you can easily set up and manage security and decryption policies for users and groups.
Cloud Identity Engine works with both on-premises Active Directory and Azure Active Directory.
To set up Cloud Identity Engine with
Prisma Access
, start by going to the hub to activate Cloud Identity Engine and to add it to
Prisma Access
. Then go to
Prisma Access
to validate that
Prisma Access
is able to access directory data.
  1. Activate Cloud Identity Engine
    Cloud Identity Engine can share Active Directory information with any supported app on the hub. It’s free and does not require an auth code to get started. Cloud Identity Engine setup includes activating the Cloud Identity Engine app on the hub, configuring the Cloud Identity Engine agent to gather Active Directory mappings, and configuring mutual authentication between Cloud Identity and and the agent.
    Make sure to deploy the Cloud Identity Engine instance in the same region that you deployed
    Prisma Access
    and Cortex Data Lake.
  2. Enable Cloud Identity Engine for
    Prisma Access
    .
    You can associate
    Prisma Access
    with Cloud Identity Engine when you’re first activating
    Prisma Access
    or anytime after:
    • While you’re activating
      Prisma Access
      :
      When you first activate Cloud Managed Prisma Access, you can choose a Cloud Identity Engine instance for
      Prisma Access
      to use. Make sure to select an instance that is deployed in the same region as
      Prisma Access
      .
    • After you’ve activated
      Prisma Access
      :
      To enable Cloud Identity Engine for an existing
      Prisma Access
      instance, log in to the hub. From the hub settings dropdown (see the gear on the top menu bar), select
      Manage Apps
      . Find the
      Prisma Access
      instance you want to update, and select the Cloud Identity Engine instance you want
      Prisma Access
      to use.

Panorama

Prisma Access
retrieves user and group information from your organization’s cloud directory or Active Directory (AD), to enforce user- and group-based policy. Optionally,
Prisma Access
retrieves user behavior-based risk signals from some cloud directory vendors, such as Azure Active Directory, to enforce automated security actions. You can simplify the retrieval of user and group information by using the Cloud Identity Engine.
In addition to simplifying user and group information retrieval, integrating the Cloud Identity Engine with
Prisma Access
can free up the bandwidth and load on your cloud directory or AD.
You can use the Cloud Identity Engine to retrieve user and group information for
Prisma Access
for mobile users, remote networks, or both, by completing the following steps.
The Cloud Identity Engine integration with
Prisma Access
has the following implementation restrictions:
  • Make sure that the groups you use with Cloud Identity Engine do not have any of the following special characters, because
    Prisma Access
    does not support the use of following special characters in groups and commit operations will fail:
    • " (Double quotes)
    • ' (Apostrophe)
    • < (less than sign)
    • > (greater than sign)
    • & (ampersand)
  • If you associate Cloud Identity Engine with
    Prisma Access
    , your user names must use the NetBIOS format that includes the domain. You can specify usernames in email format (
    username
    @
    domain
    ),
    NetBIOS\sAMAccountName
    format, or User Principal Name (UPN) format (
    username
    @
    domain
    .com).
  • Enter group names in the
    distinguishedName
    format (for example,
    CN=Users,CN=Builtin,DC=Example,DC=com
    ).
  • Cloud Identity Engine does not apply any settings you specify in the group include list (
    Device
    User Identification
    Group Mapping Settings
    Group Include List
    ); instead, it retrieves user and group information from your entire configuration, including groups used in all device groups and templates.
  1. Create a Cloud Identity Engine instance for
    Prisma Access
    , and make a note of the instance name.
    When you activate the Cloud Identity Engine, it creates an instance. You use the instance name when you associate the Cloud Identity Engine with
    Prisma Access
    in a later step. Optionally, if you need to create a separate instance for
    Prisma Access
    , create it and make a note of the instance name.
  2. Configure the Cloud Identity Engine to retrieve your directory data.
  3. (
    Deployments with on-premises Active Directory only
    ) If you use an on-premises Active Directory, Install and configure the Cloud Identity Agent to communicate with your on-premises AD and configure mutual authentication between the Cloud Identity Engine service and the agent.
  4. Enable the Cloud Identity Engine on
    Prisma Access
    .
    1. On the Panorama that manages
      Prisma Access
      , select the username-to-user group mapping setting tab.
      • For a Mobile Users—GlobalProtect deployment, select
        Panorama
        Cloud Services
        Configuration
        Mobile Users—GlobalProtect
        , select the gear icon to edit the settings, then select
        Group Mapping Settings
        .
      • For a Mobile Users—Explicit Proxy deployment, select
        Panorama
        Cloud Services
        Configuration
        Mobile Users—Explicit Proxy
        , select the gear icon to edit the settings, then select
        Group Mapping Settings
        .
      • For a remote network deployment, select
        Panorama
        Cloud Services
        Configuration
        Remote Networks
        , select the gear icon to edit the settings, then select
        Group Mapping Settings
        .
    2. Select
      Enable Directory Sync Integration
      to enable Cloud Identity Engine with
      Prisma Access
      .
    3. Enter the following information:
      • Enter the
        Primary Username
        . This field is required.
        The
        Primary Username
        attribute controls the formatting that is used in logs and reporting. If the primary username attribute is
        userPrincipalName
        (UPN), all the log and reporting entries display the source user in that format. Many deployments use a format of either UPN,
        sAMAccountName
        , or
        mail
        . If your organization uses another attribute, you can specify it here to ensure consistency for logging and reporting across your organization.
        If you configure Azure AD or Okta Directory as the identity provider (IdP) in the Cloud Identity Engine, specify the
        Primary Username
        as
        userPrincipalName
        .
        Prisma Access
        supports the userPrincipalName (UPN) attribute that is used with Azure AD and Okta Directory.
      • (
        Optional
        ) Enter the
        E-Mail
        attribute (such as
        mail
        ).
      • (
        Optional
        ) If you use alternate name attributes for the user, enter them. You can enter up to three alternate user names (
        Alternate User Name 1
        ,
        Alternate User Name 2
        , and
        Alternate User Name 3
        ).
    4. Click
      OK
      when complete.
  5. Commit and push (
    Commit
    Commit and Push
    ) your changes.
